DIN Spec Nylon Tubing Coils 6mm (OD) / 4mm (ID)

Semi Rigid Nylon Tubing Type 12
Manufactured in accordance to BS 5409,
DIN 73378 & DIN 74324
Flexible, Lightweight and Durable
Can be used over a wide range of temperatures
Resistant to a wide range of chemicals
High resistance to moisture absorption
Silicone Free
Available in 15 / 30 / 50 / 100 metre coils and also dispensing drums.
The Type 12 Nylon is can be used throughout the pneumatics industry, and is suitable for
air brake, fuel and lube applications and can be supplied in both Metric and Imperial sizes
in a number of colours. (Please ask if not listed)

Category:

Description

Max Work Pressure = 24 Bar
Max Burst Pressure = 96 Bar
Bend Radius = 35 mm



Part Ref OD Size ID Size Colour
15 MTR COILS
N61BK/15 6 mm 4 mm BLACK
N61R/15 6 mm 4 mm RED
N61Y/15 6 mm 4 mm YELLOW
N61B/15 6 mm 4 mm BLUE
N61G/15 6 mm 4 mm GREEN
N61N/15 6 mm 4 mm NATURAL
30 MTR COILS
N61BK/30 6 mm 4 mm BLACK
N61R/30 6 mm 4 mm RED
N61Y/30 6 mm 4 mm YELLOW
N61B/30 6 mm 4 mm BLUE
N61G/30 6 mm 4 mm GREEN
N61N/30 6 mm 4 mm NATURAL
50 MTR COILS
N61BK/50 6 mm 4 mm BLACK
N61R/50 6 mm 4 mm RED
N61Y/50 6 mm 4 mm YELLOW
N61B/50 6 mm 4 mm BLUE
N61G/50 6 mm 4 mm GREEN
N61N/50 6 mm 4 mm NATURAL
100 MTR COILS
N61BK/100 6 mm 4 mm BLACK
N61R/100 6 mm 4 mm RED
N61Y/100 6 mm 4 mm YELLOW
N61B/100 6 mm 4 mm BLUE
N61G/100 6 mm 4 mm GREEN
N61N/100 6 mm 4 mm NATURAL
