DIN Spec Nylon Tubing Coils Other Sizing

Semi Rigid Nylon Tubing Type 12
Manufactured in accordance to BS 5409,
DIN 73378 & DIN 74324
Flexible, Lightweight and Durable
Can be used over a wide range of temperatures
Resistant to a wide range of chemicals
High resistance to moisture absorption
Silicone Free
Available in 15 / 30 / 50 / 100 metre coils and also dispensing drums.
The Type 12 Nylon is can be used throughout the pneumatics industry, and is suitable for
air brake, fuel and lube applications and can be supplied in both Metric and Imperial sizes
in a number of colours. (Please ask if not listed)

Category:

Description

Part Ref OD Size ID Size Colour
15 MTR COILS
N51BK/15 5 mm 3.3 mm BLACK
N51N/15 5 mm 3.3 mm NATURAL
30 MTR COILS
N51BK/30 5 mm 3.3 mm BLACK
N51N/30 5 mm 3.3 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N615BK/15 6 mm 3 mm BLACK
N615N/15 6 mm 3 mm NATURAL
30 MTR COILS
N615BK/30 6 mm 3 mm BLACK
N615N/30 6 mm 3 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N815BK/15 8 mm 5 mm BLACK
N815N/15 8 mm 5 mm NATURAL
30 MTR COILS
N815BK/30 8 mm 5 mm BLACK
N815N/30 8 mm 5 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N915BK/15 9 mm 6 mm BLACK
N915N/15 9 mm 6 mm NATURAL
30 MTR COILS
N915BK/30 9 mm 6 mm BLACK
N915N/30 9 mm 6 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N1115BK/15 11 mm 8 mm BLACK
N1115N/15 11 mm 8 mm NATURAL
30 MTR COILS
N1115BK/30 11 mm 8 mm BLACK
N1115N/30 11 mm 8 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N122BK/15 12 mm 8 mm BLACK
N122N/15 12 mm 8 mm NATURAL
30 MTR COILS
N122BK/30 12 mm 8 mm BLACK
N122N/30 12 mm 8 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N1315K/15 13 mm 10 mm BLACK
N1315N/15 13 mm 10 mm NATURAL
30 MTR COILS
N1315BK/30 13 mm 10 mm BLACK
N1315N/30 13 mm 10 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N1415BK/15 14 mm 11 mm BLACK
N1415N/15 14 mm 11 mm NATURAL
30 MTR COILS
N1415BK/30 14 mm 11 mm BLACK
N1415N/30 14 mm 11 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N152BK/15 15 mm 11 mm BLACK
N152N/15 15 mm 11 mm NATURAL
30 MTR COILS
N152BK/30 15 mm 11 mm BLACK
N152N/30 15 mm 11 mm NATURAL
Part Ref OD Size ID Size Colour
15 MTR COILS
N2225BK/15 22 mm 17 mm BLACK
30 MTR COILS
N2225BK/30 22 mm 17 mm BLACK
Part Ref OD Size ID Size Colour
15 MTR COILS
N283BK/15 28 mm 22 mm BLACK
30 MTR COILS
N283BK/30 28 mm 22 mm BLACK
